IT62H Integrated Toolcarrier

Performance you can feel with the capability to work in the most demanding applications. Unmatched operator comfort and efficiency in a world class cab. Revolutionary electronics and hydraulics for low-effort operation. Increased productivity with lower owning and operating costs.

Request Quote

Download a Product Brochure

Please contact your nearest store for rates and other details.

Product Specs

Engine

Net Power - ISO 9249: 211 HP
Net Power - ISO 9249: 211.0 hp
Engine Model: Cat? C7 ACERT?
Engine Model: Cat® C7 ACERT™
Net Power - 80/1269/EEC: 211 HP
Net Power - 80/1269/EEC: 211.0 hp
Flywheel Power: 211.88 HP
Flywheel Power: 211.88 hp
Gross Power - SAE J1995: 230 HP
Gross Power - SAE J1995: 230.0 hp
Net Power - SAE J1349: 209 HP
Net Power - SAE J1349: 209.0 hp
Peak Torque - 1,400 rpm - Net: 669 ft-lb
Bore: 4.33 in
Bore: 4.33 in
Stroke: 5 in
Stroke: 5.0 in
Displacement: 439 in³
Displacement: 439.0 in3

Weights

Operating Weight: 42770 lb
Operating Weight: 42770.0 lb

Buckets

Bucket Capacities: 3.25-4.25 m3 4.25-5.5 yd3
Bucket Capacities: 3.25-4.25 m3 4.25-5.5 yd3
Maximum Bucket Capacity: 5.5 yd³
Maximum Bucket Capacity: 5.5 yd3
Bucket Width: 9.47 ft
Bucket Width: 9.47 ft
Capacity - Reference bucket: 4.25 yd³
Capacity - Reference bucket: 4.25 yd3
Type - Reference bucket: Material Handling
Type - Reference bucket: Material Handling
Breakout Force - Reference Bucket: 35775 lb
Breakout force of Reference bucket: 35775.0 lb

Transmission

Forward - 1: 4.3 mile/h
Forward 1: 4.3 mph
Forward - 2: 8.1 mile/h
Forward 2: 8.1 mph
Forward - 3: 14 mile/h
Forward 3: 14.0 mph
Forward - 4: 23.6 mile/h
Forward 4: 23.6 mph
Reverse - 1: 4.7 mile/h
Reverse 1: 4.7 mph
Reverse - 2: 8.6 mile/h
Reverse 2: 8.6 mph
Reverse 3: 15.2 mph
Reverse - 3: 15.2 mile/h
Reverse 4: 24.9 mph
Reverse - 4: 24.9 mile/h

Axles

Front: Fixed front
Front: Fixed front
Rear: Oscillating +/- 13°
Rear: Oscillating +/- 13?
Maximum Single-Wheel Rise and Fall: 18.5 in
Maximum Single-Wheel Rise and Fall: 18.5 in

Brakes

Brakes: Meets required standards.
Brakes: Meets required standards.

Hydraulic System

Bucket/Work Tool System - Pump Output: 71 gal/min
Steering System - Pump Type: Piston
Hydraulic Cycle Time - Raise: 6 s
Hydraulic Cycle Time - Dump: 2.1 s
Hydraulic Cycle Time - Dump: 2.1 Seconds
Hydraulic Cycle Time - Lower, Empty, Float Down: 2.6 s
Hydraulic Cycle Time - Total: 10.7 s
Pilot System - Pump Output: 71.33 gal/min

Service Refill Capacities

Fuel Tank - Standard: 83 gal (US)
Fuel Tank - Standard: 83.0 gal
Cooling System: 11 gal (US)
Cooling System: 11.0 gal
Crankcase: 7.9 gal (US)
Crankcase: 7.9 gal
Transmission: 9 gal (US)
Transmission: 9.0 gal
Differential - Final Drives - Front: 9.5 gal (US)
Differentials and Final Drives - Front: 9.5 gal
Differential - Final Drives - Rear: 9.5 gal (US)
Differentials and Final Drives - Rear: 9.5 gal
Hydraulic Tank: 29 gal (US)
Hydraulic Tank: 29.0 gal

Cab

ROPS/FOPS: Meets SAE and ISO standards.
ROPS/FOPS: Meets SAE and ISO standards.

Tires

Tires: Choose from a variety of tires to match your application.
Tires: Choose from a variety of tires to match your application.

Operating Specifications

Dump Clearance: 9137.11 ft
Dump Clearance: 9137.11 ft
Static Tipping Load, Full Turn: 25860.19 lb
Static Tipping Load - Full Turn: 25860.19 lb
Breakout Force: 35775.0 lb
Breakout Force: 35775 lb
Static Tipping Load - Full Turn - Bucket: 25865 lb
Static Tipping Load - Full Turn - Forks: 17515.71 lb

Dimensions

Height to top of ROPS: 11.33 ft
Height - Top of ROPS: 11.33 ft
Height to top of exhaust pipe: 11.05 ft
Height - Top of Exhaust Pipe: 11.05 ft
Height to top of hood: 8.08 ft
Height - Top of Hood: 8.08 ft
Ground clearance: 1.35 ft
Ground Clearance: 1.35 ft
B-Pin Height - Standard: 13.53 ft
Centerline Rear Axle to Edge of Counterweight: 6.56 ft
Wheelbase: 10.99 ft
Wheel Base: 10.99 ft
Center line rear axle to hitch: 5.5 ft
Centerline of Rear Axle to Hitch: 5.5 ft
Rack Back - Carry: 51 °
Rack Back - Ground: 44 °
Hook Reach at Maximum Lift - Extended: 10.47 ft
Hook Reach at Maximum Lift - Mid-Position: 8.82 ft
Hook Reach at Maximum Lift - Retracted: 7.18 ft
Hook Height at Maximum Lift - Extended: 24.89 ft
Hook Height at Maximum Lift - Mid-Position: 22.67 ft
Hook Height at Maximum Lift - Retracted: 20.45 ft
Hook Reach with Lift Arm Level - Retracted: 13 ft
Hook Reach with Lift Arm Level - Mid-Position: 15.62 ft
Hook Reach with Lift Arm Level - Extended: 18.24 ft
Hook Height with Lift Arm Level: 6 ft
Hook Reach at Minimum Lift - Retracted: 7.18 ft
Hook Reach at Minimum Lift - Mid-Position: 8.82 ft
Hook Reach at Minimum Lift - Extended: 10.47 ft
Hook Height at Minimum Lift - Retracted: 6.28 ft
Hook Height at Minimum Lift - Mid-Position: 8.33 ft
Hook Height at Minimum Lift - Extended: 10.38 ft
Overall Length - With Fork Level on Ground: 29.91 ft
Overall Reach with Lift Arm and Fork Level: 6.39 ft
Tine Height at Maximum Lift with Fork Level: 12.52 ft
Tine Height with Lift Arm and Fork Level: 5.76 ft
Fork Tine Length: 5 ft

Standard Equipment

Electrical
- Alarm, back-up
- Alternator, 80-amp brushless
- Batteries, Maintenance free (2) 1400 CCA
- Ignition key; start/stop switch
- Lighting system, halogen (6 total)
- Main disconnect switch
- Receptacle, starting, 24-volt
- Starter, electric, heavy-duty
- Starting and charging system (24-volt)
Operator Environment
- Bucket/work tool function lockout
- Cab, pressurized and sound-suppressed ROPS/FOPS
- Cigar lighter and ashtray (12-volt)
- Coat hook (2) with straps
- Computerized monitoring system
- Controls, electrohydraulic, lift and tilt function
- Heater and defroster
- Horn, electric (steering wheel/console)
- Light, dome (cab)
- Lunchbox, beverage holders and personal tray
- Mirror, rearview (internally mounted)
- Seat, Cat Comfort (cloth) with air suspension
- Seat belt, retractable, 51 mm (2") wide
- Steering column, adjustable angle
- Wet-Arm wipers and washers, front and rear
- Window, sliding (left and right side)
Power Train
- Brakes, full hydraulic enclosed wet-disc with Integrated Braking System (IBS) and brake wear indicator
- Driveline, extreme service (front)
- Engine, Cat C7 with ACERT Technology and ATAAC
- Fan, radiator, electronically controlled, hydraulically driven, temperature sensing, on demand
- Filters, fuel, primary/secondary
- Filters, engine air, primary/secondary
- Fuel priming pump (electric)
- Fuel/water separator
- Muffler, sound suppressed
- Precleaner, engine air intake
- Radiator, unit core
- Starting aid, air inlet heater
- Switch, transmission neutralizer lockout
- Torque converter, free wheel stator
- Transmission, automatic, planetary powershift (4F/4R)
- Variable Shift Control (VSC)
Other
- Automatic work tool positioner
- Counterweight
- Couplings, Caterpillar O-ring face seal
- Doors, service access (locking)
- Ecology drains, engine, transmission and hydraulics
- Fenders, steel (front and rear)
- Guard, crankcase
- Hitch, drawbar with pin
- Hood, non-metallic, power tilting
- Hoses, Caterpillar XT^™
- Hydraulic oil cooler
- Hydraulics, two-function, pilot controls
- Kickout, lift and tilt, automatic (in-cab adjustable)
- Linkage, 8-bar, parallel lift
- Oil sampling valves
- Product Link ready
- Quick coupler, hydraulically actuated
- Remote diagnostic pressure taps
- Service center, electrical and hydraulic
- Sight gauges:
- Steering, load sensing
- Vandalism protection caplocks
Tires, Rims, Wheels
- A tire must be selected from the mandatory attachments section. Base machine price includes an allowance based on a premium radial tire.
Antifreeze
- Premixed 50% concentration of Extended Life Coolant with freeze protection to -34°C (-29°F)

Attachments

Differentials
- Limited slip, front or rear
- NO-SPIN, rear
Special Machine Arrangements
- Industrial Loader Arrangement
