CB64 Vibratory Asphalt Compactors
Please contact your nearest store for rates and other details.
Product Specs
Weights
- Operating Weight
- 28616 lb
Operating Specifications
- Standard Compaction Width
- 84 in
- Curb Clearance
- 34 in
- Turning Radius - Inside Drum Edge
- 12.92 ft
- Ground Clearance
- 8.5 in
- Travel Speed - Maximum
- 8 mile/h
- Static Linear Load
- 170 lb/in
Engine
- Gross Power
- 137 hp
- Engine Model
- C4.4 with ACERT
Service Refill Capacities
- Fuel Tank Capacity
- 50 gal (US)
- Water Spray Tank Capacity
- 290 gal (US)
Dimensions
- Overall Length
- 194 in
- Wheel Base
- 143 in
- Overall Width
- 92 in
- Drum Diameter
- 51 in
- Drum Width
- 84 in
- Maximum Machine Height
- 121 in
Vibratory System
- Centrifugal Force per Drum - Maximum
- 31100 lb
- Centrifugal Force per Drum - Minimum
- 12.4 lb
- Frequency
- 63.3/42 Hz (3,800/2,520 vpm)
- Nominal Amplitude - High
- 0.04 in
- Nominal Amplitude - Low
- 0.016 in
Attachments
- Versa Vibe™ Vibratory System
- Offset Hitch
- Water Distribution Mats
- Cocoa Mats
- Water Spray Freeze Protection Kit
- Drum Covers
- High Intensity Discharge Lights
- Warning Beacon
- Bio-Degradeable Oil
- Product Link
- Drum Edge Lighting Package
