Product Specs
Engine Specifications
- Maximum Rating
- 1895 BHP
- Emissions
- NSPS Site Compliant Capable
- Displacement
- 7762 in³
- Minimum Rating
- 1775 BHP
- Compression Ratio
- 9.2:1
- Aspiration
- Turbocharged-Aftercooled
- Rotation from Flywheel End
- Counterclockwise
- Flywheel Teeth
- 255
- Weight - Dry
- 34560 lb
- Oil Change Interval
- 5000 hours
- Ignition, Protection
- Electronic (ADEMâ„¢ A3)
- Stroke
- 11.8 in
- Bore
- 11.8 in
Capacity for Liquids
- Cooling System
- 106 gal (US)
- Lube Oil System - Refill
- 187 gal (US)
Standard Equipment
-
- Air Inlet System
-
- Air cleaner — standard-duty inlet air adapter
-
- Control System
-
- ADEM A3 control system provides electronic governing integrated with air/fuel ratio control and individual cylinder ignition timing control
-
- Cooling System
-
- Jacket water pump
- Jacket water thermostats and housing
- Aftercooler pump
- Aftercooler water thermostats and housing
- Single-stage aftercooler
-
- Exhaust System
-
- Dry wrapped exhaust manifolds
- Vertical outlet adapter
-
- Flywheels And Flywheel Housing
-
- SAE standard rotation
-
- Fuel System
-
- Gas admission valves with electronically controlled fuel supply pressure
-
- Ignition System
-
- A3 control system senses individual cylinder detonation and controls individual cylinder timing
-
- Instrumentation
-
- LCD display panel monitors engine parameters and displays diagnostic codes
-
- Lube System
-
- Crankcase breathers (top mounted)
- Oil cooler
- Oil filter
- Oil pan drain valve
-
- Mounting System
-
- Engine mounting feet (four total)
-
- Protection
-
- Electronic shutoff system with purge cycle
- Crankcase explosion relief valves
- Gas shutoff valve
-
- Starting System
-
- Air starting system
-
- General
-
- Paint — Cat yellow
- Vibration dampers
Attachments
-
- Air Inlet System
-
- Heavy-duty air cleaner with precleaners
- Heavy-duty air cleaner with rain protection
-
- Charging System
-
- Charging alternators
-
- Control System
-
- Custom control system software is available for nonstandard ratings. Software is field programmable using flash memory.
-
- Cooling System
-
- Expansion tank
- Flexible connections
- Jacket water heater
-
- Exhaust System
-
- Flexible bellows adapters
- Exhaust expander
- Weld flanges
-
- Fuel System
-
- Fuel filter
- Gas pressure regulator
- Flexible connection
- Low energy fuel system
- Corrosive gas fuel system
-
- Ignition System
-
- CSA certification
-
- Instrumentation
-
- Remote data monitoring and speed control
- Compatible with Cat® Electronic Technician (ET) and Data View
- Communication Device — PL1000T/E
- Display panel deletion is optional
-
- Lube System
-
- Air or electric motor-driven prelube
- Duplex oil filter
- LH or RH service
- Lube oil makeup system
-
- Mounting System
-
- Mounting plates (set of six)
-
- Power Take-offs
-
- Front stub shafts
-
- Starting System
-
- Air pressure reducing valve
- Natural gas starting system
-
- General
-
- Engine barring device
- Damper guard
