Product Specs
Generator Set Specifications
- Continuous Rating
- 1603 ekW
- Fuel Type
- Natural Gas
- Maximum Electrical Efficiency
- 41.70%
- Maximum Standby Rating
- 1603
- Frequency
- 50 Hz
- RPM
- 1500 rpm
Engine Specifications
- Engine Model
- G3516E
- Displacement
- 4210 in³
- Aspiration
- TA
- Bore
- 6.7 in
- Stroke
- 7.5 in
Generator Set Dimensions
- Length
- 219 in
- Width
- 72 in
- Height
- 92 in
- Dry Weight - Genset
- 31226 lb
Standard Equipment
-
- Air Inlet
-
- Two-element single-stage air cleaner with enclosure and service indicator
-
- Control Panels
-
- EMCP 4.3
-
- Cooling
-
- Engine driven water pumps for jacket water and after cooler
- Jacket water and SCAC thermostats
- ANSI/DN customer flange connections for JW inlet and outlet
- Cat flanges on SCAC circuit
-
- Exhaust
-
- Dry exhaust manifolds, insulated and shielded
- Center section cooled turbocharger with Cat flanged outlet
- Individual exhaust port and turbocharger outlet wired to Integrated Temperature Sensing Module (ITSM) with GECM providing alarms and shutdowns
-
- Fuel System
-
- Electronic fuel metering valve
- Fuel system is sized for 31.5 to 47.2 MJ/NM3 dry pipeline natural gas with pressure of 4.5 to 34.5KPa to the engine fuel control valve
- Throttle plate, 24V DC actuator, controlled by GECM
-
- Generator
-
- Anti-condensation space heater
-
- Starting/charging
-
- Battery with cables and rack(shipped loose)
- Battery disconnect switch
- 60A, 24V charging alternator (standard on 60Hz 1800 rpm only)
-
- General
-
- Paint - Caterpillar Yellow except rails and radiators gloss black
- Crankshaft vibration damper and guard
- Operation and maintenance manuals
- Parts book
Attachments
-
- Air Inlet
-
- Mounting stand
- Air cleaner with precleaner
-
- Control Panels
-
- Local alarm module
- Remote annuciator
- Remote Communications Module (PL1000T, PL1000E)
-
- Cooling
-
- Coolant level drain line with valves, fan with guard
- Inlet/Outlet connections
-
- Exhaust
-
- Flange
- Exhaust expander
-
- Fuel System
-
- Fuel filter
- Gas pressure regulator
-
- Generator
-
- Medium and high voltage generators and attachment
- Low voltage extension box
- Cable access box
-
- General
-
- Crankcase explosion relief valve
- Engine barring group
