Product Specs
Generator Set Specifications
- Minimum Rating
- 985 kWe
- Maximum Rating
- 1650 kWe
- Emissions/Fuel Strategy
- (WB) Stage 1 and 2
- Voltage
- 3000 to 13800 Volts
- Frequency At Speed
- 50 Hz @ 1000 / 60 Hz @ 900
- Duty Cycle
- Prime, Continuous
- Ready To Accept Loads (Preheated/Vented)
- 40 s
- Normal Ramp Up To 100% Load
- 75 s
- Emergency Ramp Up 10% To 100% Load
- 25 s
- Genset Efficiency Up To
- 43.10%
Engine Specifications
- Engine Model
- CM20C, 4-stroke-engine
- Bore
- 7.87 in
- Stroke
- 11.81 in
- Aspiration
- Turbocharged-aftercooled
- Engine Rating Range
- 1020 - 1710 kW
- Configuration
- 6,8,9 cylinder
- Fuel Type
- Diesel oil / heavy fuel oil (HFO) / crude oil
- Swept Volume
- 575 in³
- Mean Effective Pressure Up To
- 351 psi
- Specific Fuel Oil Consumption (WB I) Up To
- 0.417 Ib/kWh
- Specific Fuel Oil Consumption (WB II) Up To
- 0.417 Ib/kWh
- Specific Lube Oil Consumption
- 0.001 Ib/kWh
Generator Set Dimensions
- Length - Minimum
- 239 in
- Length - Maximum
- 281 in
- Width - Minimum
- 66 in
- Width - Maximum
- 71 in
- Height - Minimum
- 112 in
- Height - Maximum
- 119 in
- Dry Weight - Genset (minimum)
- 41447 lb
- Dry Weight - Genset (maximum)
- 66139 lb
Standard Equipment
-
- Fuel System
-
- Pre-pressure module
- Circulation module
- Separator module
- Gas valve unit (GVU) (only dual fuel (DF) and gas)
- Engine ventilation module (only dual fuel (DF) and gas)
- Ignition fuel oil module (only dual fuel (DF))
-
- Lubricating Oil System
-
- Combined module: cooling water system and lube oil system
- Piping interface module
- Lube oil separator module
-
- Cooling Water System
-
- Piping interface module
- Cooling water system with radiators
- Combined module: see lube oil system
-
- Starting System
-
- Starting air compressor module
- Starting air receiver module
-
- Combustion Air System
-
- Air filter - oil bath
- Air filter - pulse
- Air filter - pocket
-
- Exhaust System
-
- Selective catalytic reduction (SCR) system
- Oxidation catalytic (Oxicat) converter system
- Exhaust gas ventilation module (only dual fuel (DF) and gas)
- Exhaust gas silencer
-
- Control & Monitoring System
-
- Motor control center module (MCC)
- Local data panel (LDP) / generator control panel (GCP)
- Local control panel (LCP)
- Engine monitoring package
- Gas leak detection per cylinder (only dual fuel (DF) and gas)
-
- Mounting System
-
- Elastic mounting - genset/engine
