Product Specs
Engine
- Gross Power
- 303 hp
- Engine Model
- Cat® C9 ACERT™ Tier 3
- Gross Power - 1,800 rpm
- 303 hp
Operating Specifications
- Maximum Reach - With Attachment
- 28.2 ft
Weights
- Operating Weight - Without Attachment
- 67960 lb
- Operating Weight - Without Heads*
- 67960 lb
- Operating Weight - Without Heads***
- 68640 lb
Service Refill Capacities
- Cooling System
- 16.1 gal (US)
- Engine Oil
- 10.3 gal (US)
- Hydraulic Tank
- 85.3 gal (US)
- Hydraulic System
- 97.7 gal (US)
- Swing Drive
- 2.6 gal (US)
- Fuel Capacity
- 312 gal (US)
Hydraulic System
- Pumps
- Pumps
Boom System
- Bare Pin Lift at Maximum Reach - Without Head*
- 9400 kg @ 6.6 m (21,800 lb @ 21.5 ft)
- Bare Pin Lift at Maximum Reach - Without Head***
- 6400 kg @ 8.2 m (14,200 lb @ 27 ft)
- Maximum Reach - With Head*
- 28.2 ft
Power Train
- Displacement
- 537 in³
- Engine Model
- Cat® C9 ACERT™
- Gross Power - 1,800 rpm
- 303 hp
- Rated Power - 2,100 rpm
- 282 hp
Standards
- Cab
- Standards
Undercarriage
- Size/Pitch
- 330/215.9 mm (330/8.5 in)
- Track Gauge
- 2591 mm-2870 mm (102 in-113 in)
- Track Length
- 192.6 in
- Tractive Effort
- 75500 lb
- Ground Clearance
- 35 in
Operating Weights - Without Head
- Track Feller Bunchers - Long Felling Linkage
- 68640 lb
- Track Feller Bunchers - Standard Linkage
- 67960 lb
Standard Equipment
-
- Electrical
-
- 24-volt electrical system
- 2-12 volt maintenance free batteries
- 95 amp alternator
- IQAN programmable controls
- MD3 monitor screen display
- 10 - standard working lights
- 1 - standard service light
-
- Guards
-
- Twin hydraulically actuated hinged engine enclosure with warning alarm
- Engine fan guard
- Bottom guards
- Isolation mounted cab and engine
- Heavy duty radiator guard door
-
- Operator Environment
-
- OPS/FOPS/ROPS/WCB/OR-OSHA certified cab
- Dual joystick control
- Reverse slope windshield
- Air ride seat
- Skylight - alternate escape hatch
- Top rear alternate escape hatch
- 3 inch retractable seat belt
- Heater/air conditioner with climate control
- DIN mount radio ready with speakers
- Operator sound suppression to standards
- Travel alarm
- Cup holders (2)
- 2-12 volt and 1-24 volt power outlets
- Front window, 31.75 mm (1.25 in) thick margard
- Positive filtered ventilation, pressurized cab with bi-level air conditioner, heater and defroster with manual control
- Left side fresh air window
- Forced air fan
- Washable floor mat
- Neutral lever (lockout) for all controls
-
- Power Train
-
- C9 ACERT engine meets US EPA emission standards
- Variable travel speed
- Under hood centrifugal precleaner and primary air filter
- Heavy-duty cooling package
- Electric fuel priming pump
-
- Undercarriage
-
- Heavy duty track motor guard
- Heavy duty recoil mechanism
- Track roller guards with side access holes
- Hydraulic track adjusters
- Double flange bottom rollers
- 330 bolted, non-leveling carbody, variable gauge with GFT 80 final drives
-
- Other Standard Equipment
-
- Heavy duty hood enclosure
- Vandalism protection
- Spare hose storage area
- Flexxaire™ fan
- Fuel water separator
- 1,181 L (312 gal) fuel tank
-
- Hydraulics
-
- Dedicated fixed displacement pilot pump
- Dedicated variable displacement pumps for track and implement functions
- Variable displacement saw pump for feller buncher hydraulics only
- 325 swing drive and swing motor
- Electric hydraulic oil fill pump
- High flow hydraulic arrangement for felling heads with two cylinder arm design 180 L/min (48 gpm)
- Low flow hydraulic arrangement for felling heads with single cylinder and link design 120 L/min (32 gpm)
- 318 L (84 gal) hydraulic tank
-
- Antifreeze
-
- 50% concentration extended life coolant
Attachments
-
- Track Systems
-
- 610 mm (24 in) SG pads, clipped corners, with mud/snow reliefs
- 711 mm (28 in) SG pads, clipped corners, with mud/snow reliefs
- 711 mm (28 in) DG pads, with mud/snow reliefs
- Star carrier rollers
- Standard single flange carrier rollers
-
- Other Equipment
-
- Starting aid, cold weather
- Starting aid, arctic - includes engine and hydraulic heaters
- HID Light Group - replaces 6 standard lights
-
- Field Installed Attachments
-
- CD player with AM/FM stereo - remote capable
- Skylight, peaked, removable
- Loose linkage arrangements
