Product Specs
Engine
- Engine Model
- Cat C7.1 ACERT
- Net Flywheel Power
- 235 hp
- Bore
- 4.13 in
- Stroke
- 5.31 in
- Displacement
- 428 in³
- Gross Power - SAE J1995:2014
- 239 hp
- Net Power - SAE J1349:2011
- 235 hp
- Engine RPM - Operation
- 1750 r/min
- Engine RPM - Rating
- 1800 r/min
Weights
- Operating Weight
- 69950 lb
Drive
- Maximum Drawbar Pull
- 55528 lbf
- Maximum Travel Speed
- 3.2 mile/h
- Maximum Gradeability
- 35°/70%
Service Refill Capacities
- Fuel Tank Capacity
- 137.4 gal (US)
- Cooling System
- 7.9 gal (US)
- Final Drive - Each
- 1.6 gal (US)
- Hydraulic System - Including Tank
- 81.9 gal (US)
- Hydraulic Tank
- 46.2 gal (US)
- DEF Tank
- 10.8 gal (US)
- Engine Oil - With Filter
- 6.3 gal (US)
- Swing Drive - Each
- 2.3 gal (US)
Machine Weight
- Maximum Operating Weight**
- 69950 lb
- Minimum Operating Weight*
- 64220 lb
- Note (1)
- *6.15 m (20'2") Reach Boom, R2.65CB2 (8'8") Stick, 600 mm (24") TG Shoes, 5.8 mt (6.3 t) Counterweight, 1.76 m3 (2.30 yd3) GD Bucket.
- Note (2)
- **10.2 m (33'6") SLR Boom, 7.85 m (25'9") Stick, 800 mm (31") TG Shoes, 6.75 mt (7.4 t) Counterweight, 0.53 m3 (0.70 yd3) Bucket.
Sound Performance
- ISO 6395 - Spectator Noise
- 104 dB(A)
- ISO 6396 - Operator Noise (Closed)
- 72 dB(A)
Dimensions - Reach Boom - 6.15 m (20'2)
- Shipping Length
- 34.08 ft
- Cab Height - With Top Guard
- 10.67 ft
- Ground Clearance
- 1.58 ft
- Tail Swing Radius
- 10.17 ft
- Transport Width - 800 mm (32 in) Shoes
- 11.08 ft
- Counterweight Clearance**
- 3.67 ft
- Transport Width
- 10.83 ft
- Shipping Height*
- 11.08 ft
- Track Gauge
- 8.5 ft
- Transport Width - 600 mm (24 in) Shoes
- 10.5 ft
- Note (1)
- *Including shoe lug height.
- Note (2)
- **Without shoe lug height.
Working Ranges - Reach Boom - 6.15 m (20'2)
- Maximum Cutting Height
- 32.83 ft
- Maximum Reach - Ground Level
- 35 ft
- Maximum Vertical Wall Digging Depth
- 19.58 ft
- Maximum Digging Depth
- 23.75 ft
- Maximum Loading Height
- 22.83 ft
- Minimum Loading Height
- 7.5 ft
Swing
- Swing Speed
- 9.6 r/min
Hydraulic System
- Main System - Maximum Flow - Total
- 130 gal/min
- Maximum Pressure - Equipment - Normal
- 5076 psi
- Maximum Pressure - Swing
- 3974 psi
- Maximum Pressure - Travel
- 5366 psi
- Pilot System - Maximum Flow
- 6.1 gal/min
- Pilot System - Maximum Pressure
- 595 psi
- Maximum Pressure - Equipment - Heavy Lift
- 5511 psi
Dimensions
- Maximum Depth Cut for 2440 mm (8'0") Level Bottom
- 23.25 ft
