Product Specs
Engine
- Gross Power
- 46 hp
- Displacement
- 135 in³
- Engine Model
- Cat C2.2
Operating Specifications
- Standard Paving Width
- 1400 mm - 2600 mm (4.6 - 8.5 ft)
- Paving Width Minimum
- 0.5 ft
- Paving Width Maximum
- 11.08 ft
- Hopper Capacity
- 109 ft³
- Truck Dump Height
- 23 in
- Inside Turn Radius
- 2.3 ft
- Truck Entry Width
- 9.8 ft
- Maximum Paving Speed - With Vibratory Screed
- 108 ft/min
- Maximum Travel Speed
- 2 mile/h
Weights
- Maximum Operating Weight
- 9921 lb
- Operating Weight - With Screed
- 9921 lb
Drive System
- Maximum Paving Speed
- 108.27 ft/min
Service Refill Capacities
- Fuel Tank Capacity
- 17 gal (US)
- Hydraulic Oil Tank
- 19.28 gal (US)
- Cooling System
- 4.49 gal (US)
Hopper
- Hopper Capacity
- 109.48 ft³
Dimensions
- Track Contact Length
- 4.6 ft
- Overall Height
- 8.3 ft
- Inside Turn Radius
- 2.3 ft
- Maximum Height
- 8.3 ft
- Length - With Push Roller and Largest Screed
- 13.8 ft
- Length - With Push Roller and Screed
- 13.8 ft
- Tractor Operating Width
- 9.83 ft
- Transport Height
- 5.75 ft
- Transport Width - Hoppers Raised - Screed End Gates Attached
- 5.25 ft
Attachments
- Power supply, 110V or 230V
- Grade & Slope Control
- Mechanical Feed Sensor
- Central Paving Width Reduction Package - 0.5 m to 1.40 m
- Right Side Paving Width Reduction Package - 0.15 m to 1.00 m
- Mechanical (bolt-on) extensions to reach 3.40 m paving width
