Product Specs
Dimensions
- Maximum Cutting Depth
- 23.6 in
- Wheel Width
- 7.9 in
- Weight
- 3075.4 lb
- Overall Width
- 72.8 in
- Overall Height
- 69.5 in
- Length
- 93.1 in
- Required Hydraulics
- High Flow XPS
- Optimal Hydraulic Flow
- 125 L/min (33 gpm)
- Optimal Hydraulic Pressure
- 230 bar (3336 psi)
- Motor Displacement
- 102.9 in³/rev
- Wheel Torque at Maximum Pressure
- 5538.4 lb/ft
- Wheel Speed at Maximum Flow
- 74 rpm
- Bit Speed at Maximum Flow
- 1181.1 ft/min
- Conical Bits - Per Wheel
- 96
- Standard Bit Type
- Concrete
- Optional Bit Type
- Standard
- Side Shift Travel
- 21.7 in
- Trench Cleaning Device
- Yes
- Drive Method
- Piston motor/Planetary
- Interface Type
- Skid Steer Coupler
